The BelGAS CP P8100 series is a mechanically operated liquid level controller with a flexible yet rugged
design that allows it to perform optimally in the harshest environments. Trim options for the pilot valve,
arm, spring and displacer provide the versatility to set the controller to a wide range of spans, levels, and use in most fluids.
Snap or Throttle Valves: The snap pilot provides an output of 0 to full supply within the desired span; while the throttle pilot provides a proportional
output of 0 to full supply across the entire desired span.
Sealed and Vented Case: The case is designed to keep the internal mechanism isolated from the weather while also allowing gasses from the pilot valves to escape.
Field Reversible: The unit can easily be reoriented to left handed or right handed and direct or reverse acting in the field using the insturctions included.
Adjustable Level and Span: With simple internal adjustments to the spring (level) and sensitivity arm (span) the unit can provide a wide range of options. Instructions are listed
on the inside of the door for easy access.
